BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle

Certification
China Shenzhen Baidun New Energy Technology Co., Ltd. certification
China Shenzhen Baidun New Energy Technology Co., Ltd. certification
I'm Online Chat Now

BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle

BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle
BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle

Large Image :  BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle

Product Details:
Place of Origin: Guangdong, China
Brand Name: BAIDUN
Certification: CE、FC、MSDS、ROHS、UN
Model Number: 3.2V280Ah
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: The box size is 370*260*240mm, using high-density foam, one box contains two batteries
Delivery Time: 5-8 working days
Payment Terms: Credit card, T/T,PayPal
Supply Ability: ≥50000 pieces/month

BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle

Description
Type: Li-Ion Weight: 5220±200g
Keywords: Lithium Ion Battery Cycle Life: 3500 Times
Self^discharge Rate Per Month: Electric Vehicle Nominal Voltage: 3.2V
AC Impedance Resistance: <0.25 MΩ Dimension: 207*174*72mm
High Light:

3.2v Lithium Battery For Electric Vehicle

,

Electric Vehicle 3.2v lithium ion battery

,

CC CV 3.2v lithium ion battery

Rechargeable Batteries Lithium Ion Battery3.2V 280Ah Lithiumion Cell For Electric Vehicle


Product description

This product is an upgraded version of 3.2V280AH N series 3500 cycle rechargeable Lifepo4 battery, an original brand with a unique QR code, Grade A+, a capacity of up to 290AH, good discharge performance, and a wide range of applications. It can be made in series or parallel 12V24V48V or even larger battery packs can be used for various electric vehicles and household energy storage solar energy storage off-grid needs


Battery Pack 280AH General Technical Parameter
Model
LF280


Nominal voltage
3.2V
Charge voltage
3.65V
Nominal capacity
280Ah
Battery type
Lifepo4 battery cell
Internal resistance
≤0.25mΩ
Max charge current
280A
Standard discharge current
(25±2) °C, 1.0C constant current discharge
Max discharge current
At 0 ° C ~ 45 ° C, the battery is the most

The large charging current does not exceed 1C.
Discharge cut off voltage
2.5V
Charge method
CC/CV
Net weight
5220±200g
Lifecycle
3500 times
Warranty
12 months
Charge temperature
0°C ~ 45°C
Discharge temperature
-10°C ~ 60°C
Product Description:
1. We order batteries directly from the brand. Guarantee A grade, brand new, genuine, sufficient capacity, voltage, resistance, and data matching.

2. There are three styles of battery terminals to choose from. They are: original terminals, screw holes and solder studs. Stud M6. Generally, welding studs are easier to assemble.

3. A battery is equipped with a bus bar and two screws as standard. [Bus size: 90*20*2mm (copper nickel plated) screw size: M6]

4. Lithium battery modules are connected in parallel or in series

5. Warranty period: 3 years
BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle 0
BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle 2
BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle 5
BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle 7
Our Advantages
BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle 10
Package & Shipment
BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle 12
FAQ
BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle 14
BAIDUN CC CV 3.2v Lithium Ion Battery For Electric Vehicle 16
