|Product Name:||LifePO4 Battery 100AH||Size:||51*161*118mm|
|Cycle Life:||4000 Cycles||Nominal Voltage:||12V 4S1P|
|Terminal:||Welding Studs||Screw Hole:||M8|
|Usage:||Electric Car Battery Cell And Home Energy Storage||Warranty:||3 Years|
ROHS 12v 100ah lifepo4 battery 4S1P,
baidun 12v 100ah lifepo4 battery,
baidun 12v 100ah Electric Vehicle lifepo4 battery
This is the model 3.2V 100AHL solar energy storage system Lifepo4 battery. Genuine well-known brand, the battery has 4000 cycles, has the original QR code, the quality is very good, the actual capacity is higher than the specification, can be as high as 105AH or more, it has 2000 cycles of DOD80%, and the internal resistance is less than 0.5mΩ. Adopt square aluminum shell structure, safe explosion-proof and no leakage. It has a wide range of applications and can be made into 12V24V48V or even larger battery packs in series or parallel. It can be used for various electric vehicle, home energy storage, communication energy storage and solar energy storage off-grid needs.
|1||Nominal Capacity||100.0 Ah||(25±2) °C, Standard charge and discharge|
|2||Typical Voltage||3.2 V|
|3||AC Impedance Resistance( 1 KHz)||<0.5 mQ|
|4||Dimension||Width||160 ±0.5 mm||Refer to Appendix I|
Thickness (under 20 kgf,
30%〜40% SOC )
|49.9 ±0.5 mm|
|Average thickness (200 pcs, under 300+20 kgf, 30%〜40% SOC )||49.9 ±0.5 mm|
|6||High (total)||118.5 ±0.5 mm|
|7||High (subject)||115.7 ±0.5 mm|
|8||Tabs Distance||97±0.3 mm|
|9||Battery weight||1.98±0.05 kg|
|10||Recommended scope of SOC||10% 〜90%|
|11||Charging Temperature||0 °C〜55 °C||According to continuous / pulse charge and discharge ammeters|
|12||Discharging Temperature||-20 °C~55 °C|
|13||Standard charge and discharge||Charge / discharge current||0.5 C/0.5 C|
|Cut off voltage of charge / discharge||3.65 V/2.5 V|
|14||Maximum charge / discharge current||Continuous charge / discharge||1 C/1 C||According to continuous / pulse charge and discharge ammeters|
|Pulse charge / discharge (30s)||2C/2C|
|15||Storage temperature||Short term (within 1 month)||-20°C-45°C||N.A.|
|Long term (within 1 year)||0°C 〜35°C|
|16||Storage humidity range||<95%|
|17||Self^discharge rate per month||<3%/month||Temperature: (25±2)°C, Storage scope of SOC: 30% 〜50%SOC|
End of life managem
|During the use of the battery, the battery s hall be stopped when the end of life regul ations are exceeded.|
cycle life at
|>4000 cycle @1.0C/1.0C||Under the 200kgf clamp, after standard charged and 30mins rest, discharge to 2.5V cutoff with the current of 0.5C(A) at (25±2) °C, and then start the next cycle, end with the capacity decreasing to 80% of the
initial capacity. The number of cycles is defined as the cycle life of the battery.
cycle life at
|>1800 cycle @1.0C/1.0C||Under the 300kgf clamp, after standard charged and 30mins rest, discharge to 2.5V cutoff with the current of 0.5C(A) at (45±2) °C, and then start the next cycle, end with the capacity decreasing to 80% of the initial capacity. The number of cycles is defined as the cycle life of the battery.|
Why choose Baidun
1. We provide one-stop power solutions to save design time and cost for customers:
-- Package Design/Case Design/BMS Design
2. Strict quality control system to improve the competitiveness of customers:
-- 100% PCM test passed IQC
-- OQC 100% capacity test
3. On-time delivery and excellent service:
-- Fast delivery within 10 days when in stock
-- 8 hour response and 48 hour resolution
4. Experienced R&D team to become a professional power solution consultant for customers:
-- Comprehensive battery testing center (safe and reliable testing)
——Powerful ODM capabilities to meet customized design requirements
Baidun has been cultivating new energy Lifepo4 lithium battery for 12 years!
The main products are lithium iron phosphate batteries, lithium titanate batteries, ternary lithium batteries, lithium ion battery cells, battery packs, portable power supplies, household energy storage, commercial off-grid energy storage and solar system chargers for solar energy storage systems.
The product application covers the three major fields of "power, consumption and energy storage". Widely used in: various electric vehicles, photovoltaic energy storage, household energy storage, signal system, emergency lighting system, communication equipment, solar energy and wind energy storage system, backup power supply for fire fighting equipment, UPS (uninterruptible power supply), portable digital products, etc. industry.
Baidun has always adhered to the business philosophy of high safety, high quality and environmental protection as its core values. Provide customers with the best overall power solutions, OEM/ODM services and comprehensive after-sales support to meet the different needs of customers! Integrity and professionalism, this is also our responsibility!
